| Steel Grade: | TP304 TP304L TP316L TP321 TP310S, Etc | Standard: | ASTM A312/A269/213, Etc |
|---|---|---|---|
| OD: | 6MM-88.9MM | WT: | 0.89MM-15MM |
| Length: | 3M/6M/6.1M 8M 12M Or Random Length | Shape: | Round And Hollow |
| Process Method: | Cold Rolled And Cold Drawn | Delivery Condition: | Annealed And Pickled |
| MTC: | EN10204.3.1 | Ends: | PE (Plain Ends) Or BE (Beveled Ends) |
| High Light: | small stainless steel pipe,2 stainless steel pipe |
||
Products Name: Certificated EN10204.3.1 Small Diameter Steel Tubes apply for Heat Exchange process for cold drawn and anneal
Description of items
| Material Grade | TP304 TP304L TP316L TP321 TP310S TP347H TP309S TP317L 904L, etc. |
| Raw Materials | Source from Tsing Shan Group, WALSIN, YXSS etc. |
| Standard | ASTM A312 A269 A213 A270 A789 A790 |
| Outer Diameter | 6MM to 89MM |
| Wall Thickness | 0.89MM to 15MM. |
| Length | 3M/6M/6.1M 8M 12M Or Random Length |
| Process Method | Cold Rolled and Cold Drawn |
| Delivery Condition | Annealed and Pickled |
| Heat Treatment | Solution annealed 1040℃ |
| NDT Testing | UT (Ultrasonic Testing), ET (Eddy Current Testing), HT (Hydrosatic Testing) |
| MTC | EN10204.3.1 |
| Ends | PE (Plain Ends) or BE (Beveled Ends) |
| Marking | Logo standard materials grade sizes heat no. Or as customers request |
| Package | Packing by bundles or Wooden Case. |
| Certificate | PED BV TUV ISO TS etc |
| Application | Heat Exchange/Boiler etc |
| Characteristic | Corrosion resistance/High temperature resistance/Non-Magnetic |
| Delivery time | Within 65 days after get the deposit. Allowing 5 days as flexibility |
| Lead Port | Ningbo or Shanghai Port China or as customer’s request |
| Price Term | FOB/CNF/CIF etc |
| Payment Term | TT 30% in advance, the balance against BL copy or LC at sight |
| Main Market | Middle East/ Southeast Asia/ South America etc |
| Advantage | Reasonable Price with Excellent Quality Materials. |
Chemical Composition
| C(max) | Si(max) | Mn(max) | P(max) | S(max) | Cr | Ni | Mo | Ti | |
| TP304 | 0.080 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0-20.0 | 8.0-10.5 | ||
| TP304L | 0.035 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0-20.0 | 8.0-12.0 | ||
| TP316L | 0.035 | 1.00 | 2.00 | 0.045 | 0.030 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | |
| TP321 | 0.080 | 1.00 | 2.00 | 0.045 | 0.030 | 17.0-19.0 | 9.0-12.0 | 0.7>5x(C+N) | |
| TP310S | 0.080 | 1.00 | 2.00 | 0.045 | 0.030 | 24.0-26.0 | 19.0-22.0 | 0.75 | |
| TP317L | 0.035 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0-20.0 | 11.0-15.0 | 3.0-4.0 |
Advantages
1.Short delivery time
2.Quality assurance
3.Competitive price
4.Superior Service
Welcome to enquiry!
