Product Details:
Payment & Shipping Terms:
|
Grade: | TP304/304L/316L/321 | OD: | 8MM-610MM |
---|---|---|---|
WT: | 0.8MM-32MM | Length: | 2M/3M/4M/5M/6M Or As Customer Request |
NAME: | Polished Ss Tubing | Process Method: | Cold Rolled And Cold Drawn |
High Light: | polished steel tube,polished stainless steel pipe |
C(max) | Si(max) | Mn(max) | P(max) | S(max) | Cr | Ni | Mo | Ti | |
TP304 | 0.080 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0-20.0 | 8.0-10.5 | ||
TP304L | 0.035 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0-20.0 | 8.0-12.0 | ||
TP316L | 0.035 | 1.00 | 2.00 | 0.045 | 0.030 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | |
TP321 | 0.080 | 1.00 | 2.00 | 0.045 | 0.030 | 17.0-19.0 | 9.0-12.0 | 0.7>5x(C+N) | |
TP310S | 0.080 | 1.00 | 2.00 | 0.045 | 0.030 | 24.0-26.0 | 19.0-22.0 | 0.75 |
3) Description:
Material Grade | TP304/316/321/310S |
Raw Materials | Source from Tsing Shan Group, WALSIN, YXSS etc. |
Standard | ASTM A312/213/269/554 |
Outer Diameter | 8MM-610MM |
Wall Thickness | 0.8MM-32MM |
Length | 2M/3M/4M/6M/12M or Random Length |
Process Method | Cold Rolled and Cold Drawn |
Delivery Condition | Annealed and Pickled |
Heat Treatment | Solution annealed 1040℃ |
NDT Testing | UT (Ultrasonic Testing), ET (Eddy Current Testing), HT (Hydrosatic Testing) |
MTC | EN10204.3.1 |
Ends | PE (Plain Ends) |
Marking | Logo standard materials grade sizes heat no. Or as customers request |
Package | Packing by bundles or Wooden Case. |
Certificate | PED BV TUV ISO TS etc |
Application | CONSTRUCTION;EQUIPMENT PLANT;NUCLEAR POWER AND SO ON |
Characteristic | Corrosion resistance/High temperature resistance/Non-Magnetic |
Delivery time | Within 55 days after get the deposit. Allowing 5 days as flexibility |
Lead Port | Ningbo or Shanghai Port China or as customer’s request |
Price Term | FOB/CNF/CIF etc |
Payment Term | TT 30% in advance, the balance against BL copy or LC at sight |
Main Market | Middle East/ Southeast Asia/ South America/South Africa etc |
Advantage | Reasonable Price with Excellent Quality Materials. |
