Product Details:
Payment & Shipping Terms:
|
| Name: | Cold Drawn Welded Tubes | SURFACE: | AP |
|---|---|---|---|
| SIZE: | 6MM-101.6MM | LENGTH: | AS CUSTOMER REQUEST |
| GRADE: | TP304/TP316L/310S | STANDARD: | ASTM A213 |
| High Light: | stainless steel boiler tubes,heat transfer tube |
||
Boiler & Heat Exchanger Stainless Steel Seamless Tube
DESCRIPTION:
Our Heat Exchanger Tube In Stainless Steels Are Suitable For All Types Of Heat Exchangers For Conveying All Types Of Gases And Liquid With Extreme Low And High Temperature Requirements, Such As Sea Water Coolers, Condensers, Evaporators, Heaters And Reheaters.
They Are Used For Heating, Re-Heating Or Cooling Of Gases, Air Or Fluids In An Extensive Range Of Industries Like Chemical Processing, Aerospace And Nuclear Power Generation, Hydro Carbon Processing And Oil Refining.
Our Heat Exchanger Tubes Are Appreciated For The Feature Such As Dimensional Accuracy, Corrosion Resistance, Easy Installation And Smooth Finishing.
| Commodity name | ASTM A213 stainless steel seamless tube for boiler/heat exchanger |
| Process method | cold rolled/cold drawn |
| Stainless steel grades | TP304/304L, TP310/S,TP316/316L, TP317L, TP321, TP347/H S31803/2205, 904L |
| Standard | ASTM A213 |
| Size | 6 - 610 mm |
| Testing |
Chemical Analysis. Air Under water Testing Ultrasonic Testing Eddy Current Testing |
| tube surface | AP Surface or polished # 180 g, 240 g, 320 g , 400 g, mirror. |
| Packing | bundle, plywood case, both end with caps,seaworthy packing. |
| Application | 1. General service 2. Curatorial Industry 3. Food Industry 4. Ornamental 5. Aerospace Industry 6. Petrochemical 7. Fluid transport 8. Nuclear Industr 9. Boiler heat- exchanger 10. Oil and gas service |
| Grade and chemical composition% | |||||||||
| C | Si | Mn | P≤ | S≤ | Cr | Mo | Ni | Other | |
| 201 | ≤0.15 | ≤1.00 | 5.5-7.5 | 0.06 | 0.03 | 16-18 | - | 3.5-5.5 | N≤0.25 |
| 202 | ≤0.15 | ≤1.00 | 7.5-10.0 | 0.06 | 0.03 | 17-19 | - | 4.0-6.0 | N≤0.25 |
| 301 | ≤0.15 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 16-18 | - | 6.0-8.0 | - |
| 302 | ≤0.15 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 17-19 | - | 8-10.0 | - |
| 303 | ≤0.15 | ≤1.00 | ≤2.00 | 0.2 | ≥0.015 | 17-19 | ≤0.6 | 8.0-10.0 | - |
| 304 | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 18-20 | - | 8-10.5 | - |
| 304L | ≤0.03 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 18-20 | - | 9-13 | - |
| 305 | ≤0.12 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 17-19 | - | 10.5-13 | - |
| 309S | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 22-24 | - | 12-15 | - |
| 310S | ≤0.08 | ≤1.5 | ≤2.00 | 0.045 | 0.03 | 24-26 | - | 19-22 | - |
| 316 | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 16-18 | 2-3 | 10-14 | - |
| 316L | ≤0.03 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 16-18 | 2-3 | 12-15 | - |
| 317 | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 18-20 | 3-4 | 11-15 | - |
| 317L | ≤0.03 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 18-20 | 3-4 | 11-15 | - |
| 321 | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 17-19 | - | 9-13 | Ti≥5×C |
| 405 | ≤0.08 | ≤1.00 | ≤1.00 | 0.04 | 0.03 | 11.5-14.5 | - | ≤0.6 | AL0.1-0.3 |
| 420F | 0.26-0.4 | ≤1.00 | ≤1.25 | 0.06 | ≥0.15 | 12-14 | ≤0.6 | ≤0.6 | - |
| 430 | ≤0.12 | ≤0.75 | ≤1.00 | 0.04 | 0.03 | 16-18 | - | ≤0.6 | |
ADVANTAGE:
a) RAW MATERIAL:TSING SHAN GROUP,WALSIN,YXSS
b) PRICE:WE CAN PROVIDE THE MOST REASONABLE PRICE
c) QUALITY:WE HAVE OUR OWNER INSPECTION TEAM,RULE,STRICTLY STANDARD AND WE ACCEPT CUSTOMER,THE THIRD PARTY INSPECT
d) CERTIFICATE:WE PASSED ISO,PED,TS,TUV CERTIFICATE
e) DELIVERY TIME:WE HAVE A LARGE STOCK OF RAW MATERIAL,WE ENSURE ALL ORDERS FINISH IN TIME
f) FACTORY:NICE OFFICE AND WORKSHOP ENVIRONMENT,COMPLETE TESTING EQUIPMENT,WE CAN LEAVE A GOOD IMPRESSION FOR YOU OR YOUR CUSTOMER
APPLICATION:
APPLY TO BOLIER & HEAT EXCHANGER,SUGAR FACTORY,EQUIPMENT FACTORY,EVAPORATOR PLANT
